Smart Grid - Electricity - VPP

Internet of Things: Better Electricity Supply and Demand Efficiency in Japan – Part 2

By Frank Piller, General Manager Products at TÜV Rheinland Japan



Demand response and virtual power plants (VPP) are expected to play a crucial role in the future, as outlined in METI’s latest Innovative Energy Strategy whitepaper. This article continues our discussion started here.

Frank Piller - TUV Rheinland JapanCommunication Standards for Demand Response

In May 2013, a METI-sponsored workshop established the “Demand Response Interface Specifications.” The most recent release of these is version 1.1., which contains specific requirements for communications between the supply side, for example electricity companies, and the demand side, such as aggregators.

These specifications are based on the OpenADR 2.0b Specifications compiled by the OpenADR Alliance.
The OpenADR Alliance, established in 2010 as an international standardization body promoting the development, adoption, and compliance of OpenADR standards, establishes the specifications for Automated Demand Response and those for the installation of communication devices, to ensure interoperability.

In 2014, OpenADR 2.0b Profile specifications were approved as a set of publicly available specifications (PAS) by the International Electro-technical Commission (IEC). At present, these specifications are being verified and commercialized in many countries and regions, especially in North America.

Smart GridIt is expected that OpenADR 2.0b will play the central role in the demonstration of demand response communication specifications not only in Japan but also in the rest of the world. In addition, the potential for applying this to virtual power plants is also being discussed, so that it might become the standard VPP communication specification.

In Japan, OpenADR is being used as a communication protocol for demand response, with ECHONET Lite, G3-PLC, Wi-SUN, Bluetooth and Wifi, etc. used for communication inside the Smart House.

VPP: Optimizing the Balance Between Electricity Supply and Demand Using Distributed Power Supplies

A virtual power plant, or VPP, is a system that controls multiple small-scale power sources or multiple electricity demand-suppression systems to unify them into what is effectively a single power plant. A VPP integrates small-scale generators or control systems using the latest information technology. This enables the creation of what becomes effectively a reliable overall power source from a cluster of small distributed generation sources. It is relatively economical to attain, as compared with the construction of a large-scale power generation plant.

This promotes the distribution of generation sources and avoids the risk of relying too heavily on a single large power station. VPPs are also useful for making more efficient use of such distributed generation sources.

Furthermore, besides being used to integrate small-scale generation facilities, VPPs can also be used to serve as an electricity demand-suppression system. For example, a VPP can be used as an effective single unit of power, to control negawatt power.

If a power shortage occurs, it is general practice to fill in the gap between supply and demand by increasing a generation plant’s operating rate. If a VPP is available, it becomes possible to compensate for the shortfall by collecting small amounts of negawatt power from households and companies that are conserving electricity at that time.

Light SwitchIn Japan, customer-side energy resources, including renewable energy (such as photovoltaic power generation), storage cells, heat pump water heaters (Ecocutes), fuel cells (ENEFIRM), and electric vehicles, are entering widespread use. In the near future, they will be optimally remote controlled by aggregators making use of the IoT.

It is recommended to use ECHONET Lite as the communication network to connect such customer-side energy resources and home appliances, including air conditioners and lighting equipment. Then, demand response signals (DR signals) of OpenADR specifications sent through an electricity operator or aggregators can be converted by the customer’s gateway device into demand response objects in the ECHONET Lite specification before being sent to household energy resource devices.

As mentioned above, if VPPs become fully available, electricity companies can save the costs of the construction and maintenance of spare generation facilities that are only used to meet temporary surges of electricity demand. Additionally, VPPs will reduce stress on the electricity grid and help facilitate the expansion of renewable energy sources. This will reduce environmental impacts, including carbon emissions, and help ensure a stable electricity supply.

At present, VPP is in the demonstration testing mode, and the present goal is the construction of a VPP system with a capacity of about 50 megawatt by 2020.

Approaching 2030

The Japanese government has compiled a prospective energy mix for 2030. In 2013, the demand for electricity in Japan was about one trillion kWh (966.6 billion kWh). The 2030 demand target has been set almost identical to that of 2013.

Assuming that the economy grows at 17 percent per annum, it will be necessary for us to save about 196.1 billion kWh in terms of electricity usage. To this end, the government intends to see the consumption of electricity reduced both by the promotion of energy conservation and the expansion of renewable energy.

To promote energy conservation, demand response and VPP, as well as such policies as the Zero Energy House (ZEH) and the Zero Energy Building (ZEB) will play important future roles.

, , , , , , , , , , ,
